Spécifications
| Modèle de Led | Cree MC-E (RGBW), Cree XB-D (Dynamic White) |
| RVBW | Rouge 650nm, Vert , Bleue 450nm, Blanc 6500K |
| Blanc Variable | 3000K (90+ CRI) / 6500K |
| Voltage | 12-24VDC |
| Puissance | 4.8W max |
| Pilotage | DMX |
| Température de fonctionnement | 0-50° C |
| Refroidissement | passif |
| BTUs | 16 max |
| Canaux DMX | RVBW: 4 Blanc Variable : 2 |
| Patch | RVBW : 1 R, 2 V, 3 B, 4 W Blanc variable : 1 CW, 2 WW |
| Addressing | Gantom Programmer App or DarkBox Programmer |
| Niveau de gradation | 0.05% |
| Matière | Aluminium |
| Finition | Noir, blanc, alu |
| Indice de protection | IP60 |
| Poids | 195gr |
| Beam / Field Angle | 1m Illuminance | 2m Illuminance | 3m Illuminance | |
| RGBW Beam / Field Angle Bare optics |
16° / 32° | 940 lx (87 fc) | 260 lx (24 fc) | 112 lx (10 fc) |
| RGBW Beam / Field Angle Narrow diffuser (C-HE10) |
18° / 36° | 771 lx (72 fc) | 218 lx (20 fc) | 98 lx (9 fc) |
| RGBW Beam / Field Angle Medium diffuser (C-HE30) |
30° / 58° | 330 lx (31 fc) | 99 lx (9 fc) | 44 lx (4 fc) |
| RGBW Beam / Field Angle Wide diffuser (C-HE80) |
55° / 98° | 100 lx (9 fc) | 28 lx (3 fc) | 13 lx (1 fc) |
| RGBW Beam / Field Angle Assymmetric diffuser |
16° / 46° short axis 39° / 67° long axis |
230 lx (21 fc) | 66 lx (6 fc) | 30 lx (3 fc) |
| DW Beam / Field Angle Bare optics |
23° / 44° | 1400 lx (130 fc) | 360 lx (33 fc) | 160 lx (15 fc) |
| DW Beam / Field Angle Narrow diffuser (C-HE10) |
24° / 46° | 900 lx (84 fc) | 263 lx (24 fc) | 115 lx (11 fc) |
| DW Beam / Field Angle Medium diffuser (C-HE30) |
34° / 63° | 460 lx (43 fc) | 125 lx (12 fc) | 55 lx (5 fc) |
| DW Beam / Field Angle Wide diffuser (C-HE80) |
55° / 99° | 114 lx (11 fc) | 35 lx (3 fc) | 16 lx (1 fc) |
| DW Beam / Field Angle Assymmetric diffuser |
30° / 50° short axis 46° / 77° long axis |
315 lx (29 fc) | 83 lx (8 fc) | 36 lx (3 fc) |
Modèles disponibles
| Dénomination | Référence | Couleur | Nombre de canaux DMX |
|---|---|---|---|
| DMX SPOT DW | GR211 | 2600K-6000K | 2 |
| DMX SPOT RGBW | GR212 | RGB + 6500K | 4 |
Ce produit peut également être produit (sur demande) en versions monochromes blanc froid ou blanc chaud
